HT7465-SOP8 - 2A, 24V, 380kHz, Asynchronous Step-Down Converter
TOP
2A Step-Down DC-DC Converter
• Input voltage range: 4.75V to 24V
• Variable output voltage range: 0.92V to 20V
• 2A output current
• Efficiency up to 92%
• Fixed 380kHz operating frequency
• 20mA shutdown current
• Internal power MOSFET switch
• Stable operation using low ESR ceramic capacitors
• Over temperature protection
• Cycle-by-cycle over current protection
• Under voltage lockout protection
• 8-pin E-SOP package
HT7465-SOP8.pdf
• Input voltage range: 4.75V to 24V
• Variable output voltage range: 0.92V to 20V
• 2A output current
• Efficiency up to 92%
• Fixed 380kHz operating frequency
• 20mA shutdown current
• Internal power MOSFET switch
• Stable operation using low ESR ceramic capacitors
• Over temperature protection
• Cycle-by-cycle over current protection
• Under voltage lockout protection
• 8-pin E-SOP package
HT7465-SOP8.pdf
- Eagle 5.11 Symbol and Footprint (4.51 KB)
