Is now available!
32-bit Arm® Cortex®-M0+ Music Synthesizer MCU  HT32F0006


The device operates at a frequency of up to 48 MHz with a Flash accelerator to obtain maximum efficiency. It provides up to 128 KB of embedded Flash memory for code/data storage and 16 KB of embedded SRAM memory for system operation and application program usage. A variety of peripherals, such as ADC, 2-channel DAC, I2C, I2S, USART, UART, SPI, QSPI, GPTM, SCTM, CRC-16/32, RTC, WDT, USB2.0 FS, 32-channel music synthesizer, SW-DP (Serial Wire Debug Port), etc., are also implemented in the device. Several power saving modes provide the flexibility for maximum optimization between wakeup latency and power consumption, an especially important consideration in low power applications.

The HT32F0006 integrates Wave Table synthesis function. It can operate up to 32 channels of Wave Table synthesis at one time and control the MIDI Engine to generate melody by setting the special registers. The Wave Table synthesis waveform is stored in external SPI Flash ROM for application flexibility. With these features, it provides enhanced functions and higher performance.

The above features ensure that the device is suitable for use in a wide range of applications, especially in areas such as electronic organs, digital pianos, electronic drums, electric guitars, electric accordions and so on.



to the Product --> HT32F0006    HT32F0006 application note_shotech_Rev00.PDF
available:       EPROM emulator kit SHOEMU2 - 2716 to 27512
                       with the option as a RAM simulator.
                       Configuration of all parameters via USB interface!




to the Produkt ---> EMU2
Breakout board with SX1503 - GPIO-Expander - SHO-IO16


- True bi-directional style I/O
- Programmable Pull-up/Pull-down
- Push/Pull outputs
- PLD Funktion
- VDDM, VCC1 and VCC2 can be independent from 1.2V to 5.5V.
- Ideal for 5V systems (VDDM = + 5V) to enable 3.3V ports (VCC1 and VCC2 -> + 3.3V).
- Ideal for 3.3V systems (VDDM = + 3.3V) to enable 5V ports (VCC1 and VCC2 -> + 5V).
- own supply on the board  ( LDO 3,3V )

to the Produkt ---> SHO-IO16
