TVS metal oxide varistor V320LA20AP, disc 14mm, 320V(AC), 420(DC), 4.5kA, 80J
TVS metal oxide varistor V320LA20AP, disc 14mm, 320V(AC), 420(DC), 4.5kA, 80J
TVS metal oxide varistor V320LA20AP, disc 14mm, 320V(AC), 420(DC), 4.5kA, 80J

TVS metal oxide varistor V320LA20AP, disc 14mm, 320V(AC), 420(DC), 4.5kA, 80J

Product No.:
002601
Shipping time:
ca. 3-5 days ca. 3-5 days (abroad may vary)
Stock:
490 pieces
RoHS:
RoHS3-konform
Delivery:
Loose in bag
Country of origin:
CN
HS code:
85332100
Sliding scale prices
1-4 units
per 0,56 EUR
5-9 units
per 0,49 EUR
10-24 units
per 0,45 EUR
25-49 units
per 0,38 EUR
50-99 units
per 0,32 EUR
> 99 units
per 0,28 EUR
0,56 EUR

incl. 19% tax excl. Shipping costs

Add to wish list
Ask about product
Description
transient voltage surge suppressors



Maximum voltage (AC) 320 V
Maximum voltage (DC) 420 V
Varistor voltage (min.) 459 V
Varistor voltage (typ.) 510 V
Varistor voltage (max.) 561 V
Current - peak current 4.5 kA
Energy 80J
Capacitance at frequency 380 pF @ 1 MHz
Operating temperature -55°C to 85°C (TA)



   Varistor-LA-Serie.pdf
