KRM-FDC2-Z80-PCB/KIT
FDC2 circuit board for the MC Z80 based on Dr. B. Fuhrmann Schematics. (Floppy controller for CP/M)
Possible order forms:
Kit PCB: PCB, male connector A+B angled 64-pin, screws, nuts.
Kit 1: Circuit board with all components, complete kit.
Kit 2: PCB, male connector A+B angled 64-pin, screws, nuts. UPD765AC and 40-pin. version
The controller used is a UPD765AC from NEC. The U8272 is also possible.
Unfortunately, the circuit could not be tested, but there are corresponding examples in the ASM code.
Information about the Kramer MC can be found here: Kramer-MC Grundgerät. and the Ausbaustufe 2 .
KRM-FDC1-Z80-Data.pdf ( no longer available ! )
KRM-FDC2-Z80-Data-Rev 02.pdf ( Latest variant A302 or TCA345A can be fitted )
Possible order forms:
Kit PCB: PCB, male connector A+B angled 64-pin, screws, nuts.
Kit 1: Circuit board with all components, complete kit.
Kit 2: PCB, male connector A+B angled 64-pin, screws, nuts. UPD765AC and 40-pin. version
The controller used is a UPD765AC from NEC. The U8272 is also possible.
Unfortunately, the circuit could not be tested, but there are corresponding examples in the ASM code.
Information about the Kramer MC can be found here: Kramer-MC Grundgerät. and the Ausbaustufe 2 .
KRM-FDC1-Z80-Data.pdf ( no longer available ! ) KRM-FDC2-Z80-Data-Rev 02.pdf ( Latest variant A302 or TCA345A can be fitted )
