DC/DC Converter SIM2-0515D-SIL7
Input: +5V
Output: ±15V 2x66mA 2W
Info:
Power: 2W
Efficiency: 80% min
Voltage accuracy: Max. ±5%
Ripple and noise: 100mV p-p max.
Load regulation ( >= 5V output ): ±8%(Load=20%-100%)
Load regulation ( < 5V output ): ±12%(Load=20%-100%)
Line regulation: ±1.2% von Vin
MTBF: 200.000 hours min.
Switching frequency: 100KHz min.
Operation temperature: -20...+75°C
Isolation voltage: 1kVDC min.
Casing: non conducting plastics
Max. capacitive load: Dual output 220µF
RoHS 2002/95/EC conform
sim2sil7.pdf
