SMini2-F5-B / SC-90A
DB2J31400L - Silicon epitaxial planar type
Preview: SMini2-F5-B / SC-90A
Preview: DB2J31400L - Silicon epitaxial planar type
DB2J31400L - Silicon epitaxial planar type
SMini2-F5-B / SC-90A
DB2J31400L - Silicon epitaxial planar type
Mobile Preview: SMini2-F5-B / SC-90A
Mobile Preview: DB2J31400L - Silicon epitaxial planar type

DB2J31400L - Silicon epitaxial planar type

Product No.:
001987
Shipping time:
ca. 3-5 days ca. 3-5 days (abroad may vary)
Stock:
22392 pieces
RoHS:
yes
Delivery:
cut tape / Reel
Country of origin:
JP
HS code:
85411000
Sliding scale prices
1-9 units
per 0,55 EUR
10-99 units
per 0,50 EUR
100-499 units
per 0,45 EUR
500-2999 units
per 0,23 EUR
3000-5999 units
per 0,19 EUR
> 5999 units
per 0,12 EUR
0,55 EUR

incl. 19% tax excl. Shipping costs

Add to wish list
Ask about product
Description
Silicon epitaxial planar type

* Short reverse recovery time trr
* Small reverse current IR
* Halogen-free / RoHS compliant
  (EU RoHS / UL-94 V-0 / MSL: Level 1 compliant)

Small reverse current IR
Small temperature coefficient of forward characteristic

Reverse voltage (DC)     VR   30 V
Peak reverse voltage    VRM   30 V
Peak forward current    IFM   150 mA
Forward current (DC)     IF   30 mA
Junction temperature     Tj   125 °C
Storage temperature     Tstg  −55 to +125 °C

Reverse current (DC)     IR VR = 30 V 300 nA
Reverse recovery time *  trr IF = IR = 10 mA 1.0 ns

Package: SMini2-F5-B /  SC-90A

Reel = 3000

DC: 2020/01

  DB2J31400L.pdf
