Elko, radial, 100 µF, 25 V, RM 2.5, Low ESR
Low Impedance
Ripple current(mA rms) 105°C 100kHz: 280 mA
Impedance(Ω) max.20°C 100kHz: 300 mOhm
D x L: 6.3 x 11 mm
High reliability withstanding 2000 hours load life at 105°C
spacing: 2.5 mm
Operating temperature range: -40 ~ +105°C
Leakage current max. I = 0.01CV or 3µA whichever is greater (after 2 minutes)
Capacitance tolerance: ±20% at 120Hz, 20°C
Part-Number: WL1E107M6L011CA
WL.pdf
